XL-2835-TF-FP-LW150-R AUDIO PIEZO INDICATOR 4-18V CHAS - ALARM, BUZZER, SIREN
0,00 TL +KDV
Elektromekanik Komponent | Ses Ürünleri | Alarm, Buzzer ve Siren Çeşitleri
XL-2835-TF-FP-LW150-R AUDIO PIEZO INDICATOR 4-18V CHAS
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | XL-2835-TF-FP-LW150-R |
| Mfr | PUI Audio, Inc. |
| Description | AUDIO PIEZO INDICATOR 4-18V CHAS |
| Series | XL |
| Driver Circuitry | Indicator, Internally Driven |
| Input Type | DC |
| Voltage - Rated | 12 V |
| Voltage Range | 4 ~ 18V |
| Frequency | 3.5kHz |
| Technology | Piezo |
| Operating Mode | Pulse, Fast |
| Duration | 3 PPS |
| Sound Pressure Level (SPL) | 92dB @ 12V, 10cm |
| Current - Supply | 5mA |
| Port Location | Top |
| Operating Temperature | -30°C ~ 85°C |
| Approval Agency | - |
| Ratings | - |
| Ingress Protection | - |
| Mounting Type | Panel Mount, Flange |
| Termination | Wire Leads |
| Size / Dimension | 1.102" Dia (28.00mm) |
| Height - Seated (Max) | 1.020" (25.90mm) |
