SC616NR AUDIO PIEZO IND 6-26V PNL MNT - ALARM, BUZZER, SIREN
0,00 TL +KDV
Elektromekanik Komponent | Ses Ürünleri | Alarm, Buzzer ve Siren Çeşitleri
SC616NR AUDIO PIEZO IND 6-26V PNL MNT
Özellik | Değer |
---|---|
Datasheet | PDF Datasheet indir |
Mfr Part # | SC616NR |
Mfr | Mallory Sonalert Products Inc. |
Description | AUDIO PIEZO IND 6-26V PNL MNT |
Series | SC |
Driver Circuitry | Indicator, Internally Driven |
Input Type | DC |
Voltage - Rated | - |
Voltage Range | 6 ~ 26V |
Frequency | 2.9kHz |
Technology | Piezo |
Operating Mode | Single Tone |
Duration | - |
Sound Pressure Level (SPL) | 80dB @ 6V, 61cm |
Current - Supply | 6 ~ 22mA |
Port Location | Top |
Operating Temperature | -30°C ~ 65°C |
Approval Agency | cUL, UL |
Ratings | - |
Ingress Protection | - |
Mounting Type | Panel Mount |
Termination | Screw Terminal, Quick Connect Tab - 0.250" (6.35mm) |
Size / Dimension | 1.687" Dia (42.85mm) |
Height - Seated (Max) | 1.399" (35.54mm) |
