PT-520-SQ AUDIO PIEZO XDCR 1-30V CHASSIS - ALARM, BUZZER, SIREN
0,00 TL +KDV
Elektromekanik Komponent | Ses Ürünleri | Alarm, Buzzer ve Siren Çeşitleri
PT-520-SQ AUDIO PIEZO XDCR 1-30V CHASSIS
Özellik | Değer |
---|---|
Datasheet | PDF Datasheet indir |
Mfr Part # | PT-520-SQ |
Mfr | Mallory Sonalert Products Inc. |
Description | AUDIO PIEZO XDCR 1-30V CHASSIS |
Series | PT |
Driver Circuitry | Transducer, Externally Driven |
Input Type | Peak-Peak Signal |
Voltage - Rated | 5 V |
Voltage Range | 1 ~ 30V |
Frequency | 4.4kHz |
Technology | Piezo |
Operating Mode | Single Tone |
Duration | - |
Sound Pressure Level (SPL) | 85dB @ 5V, 10cm |
Current - Supply | 3mA |
Port Location | Top |
Operating Temperature | -20°C ~ 70°C |
Approval Agency | - |
Ratings | - |
Ingress Protection | - |
Mounting Type | Panel Mount, Flange |
Termination | Wire Leads |
Size / Dimension | 1.614" L x 0.551" W (41.00mm x 14.00mm) |
Height - Seated (Max) | 1.437" (36.50mm) |
