Elektromekanik Komponent | Ses Ürünleri | Alarm, Buzzer ve Siren Çeşitleri

PB-4739NL PIEZO BUZZER 12V 105DB 2500HZ 47

Özellik	Değer
Datasheet	PDF Datasheet indir
Mfr Part #	PB-4739NL
Mfr	Soberton Inc.
Description	PIEZO BUZZER 12V 105DB 2500HZ 47
Series	PB
Driver Circuitry	Indicator, Internally Driven
Input Type	DC
Voltage - Rated	12 V
Voltage Range	9 ~ 15V
Frequency	2.5kHz
Technology	Piezo
Operating Mode	Single Tone
Duration	-
Sound Pressure Level (SPL)	105dB @ 12V, 30cm
Current - Supply	120mA
Port Location	Top
Operating Temperature	-20°C ~ 60°C
Approval Agency	-
Ratings	-
Ingress Protection	-
Mounting Type	Panel Mount, Flange
Termination	Wire Leads
Size / Dimension	1.850" L x 1.535" W (47.00mm x 39.00mm)
Height - Seated (Max)	0.925" (23.50mm)
