MD-HRA261-H10-2 BP DIGITAL MEMS MIC 3.5X2.65 - MIKROFON | MIC
0,00 TL +KDV
Elektromekanik Komponent | Ses Ürünleri | Mikrofon Çeşitleri
MD-HRA261-H10-2 BP DIGITAL MEMS MIC 3.5X2.65
CUI Devices mikrofon CMC-3015-44T. 100 Hz ~ 20.0 kHz, Circular, Electret Condenser, -44dB ±3dB @ 94dB SPL, Omnidirectional, Analog çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | MD-HRA261-H10-2 |
| Mfr | Gettop Acoustics |
| Description | BP DIGITAL MEMS MIC 3.5X2.65 |
| Series | - |
| Type | MEMS (Silicon) |
| Output Type | Digital, PDM |
| Direction | Omnidirectional |
| Frequency Range | 100 Hz ~ 10.0 kHz |
| Sensitivity | -26dB ±1dB @ 94dB SPL |
| S/N Ratio | 63dB |
| Impedance | - |
| Voltage - Rated | 1.8 V |
| Voltage Range | 1.62 V ~ 3.6 V |
| Current - Supply | 800 µA |
| Port Location | Bottom |
| Ratings | - |
| Termination | Solder Pads |
| Size / Dimension | 0.138" L x 0.104" W (3.50mm x 2.65mm) |
| Height (Max) | 0.043" (1.08mm) |
| Shape | Rectangular |
