IMP34DT05TR MICROPHONE MEMS DIGITAL PDM OMNI
STMicroelectronics mikrofon IMP23ABSUTR. , , , , , çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | IMP34DT05TR |
| Mfr | STMicroelectronics |
| Description | MICROPHONE MEMS DIGITAL PDM OMNI |
| Series | - |
| Type | MEMS (Silicon) |
| Output Type | Digital, PDM |
| Direction | Omnidirectional |
| Frequency Range | 100 Hz ~ 10.0 kHz |
| Sensitivity | -26dB ±3dB @ 94dB SPL |
| S/N Ratio | 64dB |
| Impedance | - |
| Voltage - Rated | 1.8 V |
| Voltage Range | - |
| Current - Supply | 650 µA |
| Port Location | Top |
| Ratings | - |
| Termination | Solder Pads |
| Size / Dimension | 0.118" L x 0.157" W (3.00mm x 4.00mm) |
| Height (Max) | 0.043" (1.10mm) |
| Shape | Rectangular |
