IM69D130V01XTSA1 MICROPHONE MEMS DIGITAL PDM OMNI - MIKROFON | MIC
0,00 TL +KDV
Elektromekanik Komponent | Ses Ürünleri | Mikrofon Çeşitleri
IM69D130V01XTSA1 MICROPHONE MEMS DIGITAL PDM OMNI
Mallory Sonalert Products Inc. mikrofon PMOF-9767NS-40DQ. 50 Hz ~ 20.0 kHz, Circular, Electret Condenser, -40dB ±2dB @ 94dB SPL, Omnidirectional, Analog çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | IM69D130V01XTSA1 |
| Mfr | Infineon Technologies |
| Description | MICROPHONE MEMS DIGITAL PDM OMNI |
| Series | - |
| Type | MEMS (Silicon) |
| Output Type | Digital, PDM |
| Direction | Omnidirectional |
| Frequency Range | 20 Hz ~ 20.0 kHz |
| Sensitivity | -36dB ±1dB @ 94dB SPL |
| S/N Ratio | 69dB |
| Impedance | - |
| Voltage - Rated | - |
| Voltage Range | 1.62 V ~ 3.6 V |
| Current - Supply | 1.3 mA |
| Port Location | Bottom |
| Ratings | - |
| Termination | Solder Pads |
| Size / Dimension | 0.157" L x 0.118" W (4.00mm x 3.00mm) |
| Height (Max) | 0.051" (1.30mm) |
| Shape | Rectangular |
