AT-2310-T-LW100-R AUDIO PIEZO XDCR 1-12V CHASSIS - ALARM, BUZZER, SIREN
0,00 TL +KDV
Elektromekanik Komponent | Ses Ürünleri | Alarm, Buzzer ve Siren Çeşitleri
AT-2310-T-LW100-R AUDIO PIEZO XDCR 1-12V CHASSIS
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | AT-2310-T-LW100-R |
| Mfr | PUI Audio, Inc. |
| Description | AUDIO PIEZO XDCR 1-12V CHASSIS |
| Series | AT |
| Driver Circuitry | Transducer, Externally Driven |
| Input Type | Peak-Peak Signal |
| Voltage - Rated | 3 V |
| Voltage Range | 1 ~ 12V |
| Frequency | 2kHz |
| Technology | Piezo |
| Operating Mode | Single Tone |
| Duration | - |
| Sound Pressure Level (SPL) | 65dB @ 3V, 10cm |
| Current - Supply | 3mA |
| Port Location | Top |
| Operating Temperature | -30°C ~ 85°C |
| Approval Agency | - |
| Ratings | - |
| Ingress Protection | - |
| Mounting Type | Custom |
| Termination | Wire Leads |
| Size / Dimension | 0.886" Dia (22.50mm) |
| Height - Seated (Max) | 0.146" (3.70mm) |
