AST0927MW-3.6TRQ SMT TRANSDUCER,2-5VAC,85DB,2730H - ALARM, BUZZER, SIREN
0,00 TL +KDV
Elektromekanik Komponent | Ses Ürünleri | Alarm, Buzzer ve Siren Çeşitleri
AST0927MW-3.6TRQ SMT TRANSDUCER,2-5VAC,85DB,2730H
Özellik | Değer |
---|---|
Datasheet | PDF Datasheet indir |
Mfr Part # | AST0927MW-3.6TRQ |
Mfr | Mallory Sonalert Products Inc. |
Description | SMT TRANSDUCER,2-5VAC,85DB,2730H |
Series | AST |
Driver Circuitry | Transducer, Externally Driven |
Input Type | Peak-Peak Signal |
Voltage - Rated | 3.6 V |
Voltage Range | 2 ~ 5V |
Frequency | 2.73kHz |
Technology | Magnetic |
Operating Mode | Single Tone |
Duration | - |
Sound Pressure Level (SPL) | 85dB @ 3.6V, 10cm |
Current - Supply | 90mA |
Port Location | Side |
Operating Temperature | -30°C ~ 70°C |
Approval Agency | - |
Ratings | - |
Ingress Protection | - |
Mounting Type | Surface Mount |
Termination | Solder Pads |
Size / Dimension | 0.354" Dia (9.00mm) |
Height - Seated (Max) | 0.126" (3.20mm) |
