AMM-2738-B-R MICROPHONE MEMS ANALOG OMNI - MIKROFON | MIC
0,00 TL +KDV
Elektromekanik Komponent | Ses Ürünleri | Mikrofon Çeşitleri
AMM-2738-B-R MICROPHONE MEMS ANALOG OMNI
Vesper Technologies Inc. mikrofon VM3000. 20 Hz ~ 8.0 kHz, Rectangular, MEMS (Silicon), -26dB ±1dB @ 94dB SPL, Omnidirectional, Digital, PDM çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | AMM-2738-B-R |
| Mfr | PUI Audio, Inc. |
| Description | MICROPHONE MEMS ANALOG OMNI |
| Series | - |
| Type | MEMS (Silicon) |
| Output Type | Analog |
| Direction | Omnidirectional |
| Frequency Range | 20 Hz ~ 20.0 kHz |
| Sensitivity | -38db ±1dB |
| S/N Ratio | 64dB |
| Impedance | 300 Ohms |
| Voltage - Rated | 2 V |
| Voltage Range | 1.5 V ~ 3.6 V |
| Current - Supply | 150 µA |
| Port Location | Bottom |
| Ratings | - |
| Termination | Solder Pads |
| Size / Dimension | 0.108" L x 0.073" W (2.75mm x 1.85mm) |
| Height (Max) | 0.039" (1.00mm) |
| Shape | Rectangular |
Bu ürüne ilk yorumu siz yapın!
